| Optic Specification |
| Optics System |
2500 Pixel CCD sensor |
Lamp-house |
RED LED (Wave length 630-660mm) |
| Scan distinguish rate |
0.1mm(4mil) |
| Deepness contrast character (PCS) |
30% or more |
| Read barcode angle |
43 degree |
| Read barcode width |
Up to 110mm or more (PCS 90%) |
| Scan distance |
4 mil;0-12mm(PCS=90%)-,5mil;0-30mm(PCS=90%)
10.5mil:0-115mm(PCS-90%)
13mil:0-140mm(PCS90%),40MIL:0-240MM(pcs-90%) |
| Interface |
Keyboard Wedge,RS232,USB interfaces |
| Decoder Symbologies |
Code39,Full ASC,Code39,Code32,Code128,Code93,Code 11,Codabar/NW7,AllUPC/EAN/JANcode |
| Decodable Symbologies |
( EAN-13,EAN-8 ,UPC-A,UPC-E,EAN-128),
Interleave 2 of 5,STD 2 of 5,Industrial 2 of 5,matrix 2of 5, Chinese Postage Code, IATA, MSI/PLESSY, Italian Pharmacy Code, Industrial 2 of 5,BC-412 |
| Option decodable |
RSS-14,RSS Limited, RSS Expanded, PDF 417 |
| Warranty |
1 year |
| Electronic Specification |
| Process |
32 bits ARM AT9XSAMXXX |
| Voltage |
4.5V-5.25V DC±5% |
| Operate standard |
100-130mA |
| Working current |
125mA |
| Operation Condition |
| Operation temperature |
+32”F to +105”F (0to + 50 degree) |
| Stock temperature |
-15”F TO +140”F(-26 to 60 degree ) |
| Operation humidity |
10% to 80% |
| Stock humidity |
10% to 90% RH |
| Anti-condition light |
10000 Lux max, (Fluorescence),5000 lux max,(sunlight) |
